"A calm pod tells you what you want to hear. A stressed pod tells you the truth"
Problem
The Kubernetes Fundamentals (LFS258) course contains multiple exercises involving the vish/stress container image. The original image is specific to x86-64 architecture, and thus if you’re like me and do the course on an Apple Silicon Mac, or Raspberry Pi or other ARM architectures, you’ll run into the following problem:
$ kubectl create deployment hog --image vish/stress
deployment.apps/hog created
$ kubectl get pod
NAME READY STATUS RESTARTS AGE
hog-7d56d5576b-mn67d 0/1 CrashLoopBackOff 2 (22s ago) 43s
$ kubectl describe pod hog-7d56d5576b-mn67d
Name: hog-7d56d5576b-mn67d
Namespace: default
Priority: 0
Service Account: default
Node: w1/172.16.188.135
Start Time: Fri, 20 Jun 2025 09:10:02 +0000
Labels: app=hog
pod-template-hash=7d56d5576b
Annotations: <none>
Status: Running
IP: 192.168.1.10
IPs:
IP: 192.168.1.10
Controlled By: ReplicaSet/hog-7d56d5576b
Containers:
stress:
Container ID: containerd://383f8975b82fd56dabac332196801239b3443a6cf2a656fd08b9a70c684bf247
Image: vish/stress
Image ID: docker.io/vish/stress@sha256:b6456a3df6db5e063e1783153627947484a3db387be99e49708c70a9a15e7177
Port: <none>
Host Port: <none>
State: Terminated
Reason: Error
Exit Code: 255
Started: Fri, 20 Jun 2025 09:10:52 +0000
Finished: Fri, 20 Jun 2025 09:10:52 +0000
Last State: Terminated
Reason: Error
Exit Code: 255
Started: Fri, 20 Jun 2025 09:10:23 +0000
Finished: Fri, 20 Jun 2025 09:10:23 +0000
Ready: False
Restart Count: 3
Environment: <none>
Mounts:
/var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-x22gl (ro)
Conditions:
Type Status
PodReadyToStartContainers True
Initialized True
Ready False
ContainersReady False
PodScheduled True
Volumes:
kube-api-access-x22gl:
Type: Projected (a volume that contains injected data from multiple sources)
TokenExpirationSeconds: 3607
ConfigMapName: kube-root-ca.crt
ConfigMapOptional: <nil>
DownwardAPI: true
QoS Class: BestEffort
Node-Selectors: <none>
Tolerations: node.kubernetes.io/not-ready:NoExecute op=Exists for 300s
node.kubernetes.io/unreachable:NoExecute op=Exists for 300s
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal Scheduled 53s default-scheduler Successfully assigned default/hog-7d56d5576b-mn67d to w1
Normal Pulled 51s kubelet Successfully pulled image "vish/stress" in 890ms (890ms including waiting). Image size: 1558791 bytes.
Normal Pulled 50s kubelet Successfully pulled image "vish/stress" in 854ms (854ms including waiting). Image size: 1558791 bytes.
Normal Pulled 33s kubelet Successfully pulled image "vish/stress" in 871ms (871ms including waiting). Image size: 1558791 bytes.
Normal Pulling 4s (x4 over 52s) kubelet Pulling image "vish/stress"
Normal Created 3s (x4 over 51s) kubelet Created container: stress
Normal Started 3s (x4 over 51s) kubelet Started container stress
Warning BackOff 3s (x5 over 50s) kubelet Back-off restarting failed container stress in pod hog-7d56d5576b-mn67d_default(0cefaf84-0063-4cdf-b3a6-2329e10ae30b)
Normal Pulled 3s kubelet Successfully pulled image "vish/stress" in 896ms (896ms including waiting). Image size: 1558791 bytes.
Before reading further, have you spotted the problem?
Troubleshooting
Yes! The container failed to start.
Warning BackOff 3s (x5 over 50s) kubelet Back-off restarting failed container stress in pod hog-7d56d5576b-mn67d_default(0cefaf84-0063-4cdf-b3a6-2329e10ae30b)
What’s happening? Let’s check the pod and see:
$ kubectl logs hog-7d56d5576b-mn67d
exec /stress: exec format error
This basically means that the container could not execute the stress binary because of mismatched architecture.
Build an ARM Docker image
Let’s delete the deployment and work on creating a container with the expected architecture. I’ve already forked the original repo. Check it out to see the differences: mainly an updated Docker file and a small change to main.go to fix some imports which changed in the meantime since the repository was last updated.
$ kubectl delete deployments.apps hog
deployment.apps "hog" deleted
$ git clone https://github.com/livz/stress.git
Cloning into 'stress'...
remote: Enumerating objects: 29, done.
remote: Counting objects: 100% (15/15), done.
remote: Compressing objects: 100% (15/15), done.
remote: Total 29 (delta 4), reused 0 (delta 0), pack-reused 14 (from 1)
Receiving objects: 100% (29/29), 1.49 MiB | 6.75 MiB/s, done.
Resolving deltas: 100% (8/8), done.
$ cd stress/
$ sudo make docker
[+] Building 1.0s (13/13) FINISHED docker:default
=> [internal] load build definition from Dockerfile 0.0s
=> => transferring dockerfile: 543B 0.0s
=> [internal] load metadata for docker.io/library/golang:latest 1.0s
=> [auth] library/golang:pull token for registry-1.docker.io 0.0s
=> [internal] load .dockerignore 0.0s
=> => transferring context: 2B 0.0s
=> [builder 1/6] FROM docker.io/library/golang:latest@sha256:10c1318..2fb99ef16deaa23e4246fc817 0.0s
=> [internal] load build context 0.0s
=> => transferring context: 1.68kB 0.0s
=> CACHED [builder 2/6] WORKDIR /app 0.0s
=> CACHED [builder 3/6] COPY main.go 0.0s
=> CACHED [builder 4/6] RUN go mod init boundsgilder/stress 0.0s
=> CACHED [builder 5/6] RUN go mod tidy 0.0s
=> CACHED [builder 6/6] RUN GOBIN=/ CGO_ENABLED=0 GOARCH=arm go build --ldflags '-extldflags "-static"' -o stress 0.0s
=> CACHED [stage-1 1/1] COPY --from=builder /app/stress / 0.0s
=> exporting to image 0.0s
=> => exporting layers 0.0s
=> => writing image sha256:5595519b77803f9b8c662098fc7406b94bb517b6d45981a7a9dde7eaa77cbc86 0.0s
=> => naming to docker.io/vish/stress 0.0s
$ sudo docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
vish/stress latest 5595519b7780 2 days ago 3.55MB
boundsgilder/stress arm64 1e7aff087584 3 days ago 3.55MB
$ sudo docker push boundsgilder/stress:arm64
The push refers to repository [docker.io/boundsgilder/stress]
c9ae5f539446: Layer already exists
arm64: digest: sha256:65db52c4726e3c2100d4d3bedbca3903e5250b275b4099b56915788d42662a8f size: 527
Verify
With the new container image build and uploaded to Docker hub, let’s create the hog deployment and container from a YAML file:
apiVersion: apps/v1
kind: Deployment
metadata:
annotations:
deployment.kubernetes.io/revision: "1"
generation: 1
labels:
app: hog
name: hog
namespace: default
resourceVersion: "118737"
spec:
progressDeadlineSeconds: 600
replicas: 1
revisionHistoryLimit: 10
selector:
matchLabels:
app: hog
strategy:
rollingUpdate:
maxSurge: 25%
maxUnavailable: 25%
type: RollingUpdate
template:
metadata:
creationTimestamp: null
labels:
app: hog
spec:
containers:
- image: boundsgilder/stress:arm64
imagePullPolicy: Always
name: hog
resources:
limits:
memory: "4Gi"
requests:
memory: "2500Mi"
terminationMessagePath: /dev/termination-log
terminationMessagePolicy: File
dnsPolicy: ClusterFirst
restartPolicy: Always
schedulerName: default-scheduler
securityContext: {}
terminationGracePeriodSeconds: 30
$ kubectl create -f hog.yaml
deployment.apps/hog created
With the deployment created, let’s check the pod:
$ kubectl get pod hog-7645f766b6-w7xx5 -o wide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
hog-7645f766b6-w7xx5 0/1 Error 2 (20s ago) 23s 192.168.1.184 w1 <none> <none>
Hey! Another error? Let’s check the logs and see what happened:
$ kubectl logs hog-6d9db4cb9d-jrv8z
F0618 20:06:02.234479 1 glog.go:261] log: exiting because of error writing previous log to sinks: log: cannot create log: open /tmp/stress.hog-6d9db4cb9d-jrv8z.unknownuser.log.INFO.20250618-200602.1: no such file or directory
goroutine 1 [running]:
github.com/golang/glog.sinkf.func1()
/home/student/go/pkg/mod/github.com/golang/glog@v1.2.5/glog.go:262 +0x110
sync.(*Once).doSlow(0x400005c1e0?, 0x154281?)
/snap/go/10881/src/sync/once.go:78 +0xf0
sync.(*Once).Do(...)
/snap/go/10881/src/sync/once.go:69
github.com/golang/glog.sinkf(0x400005c1e0, {0x154281?, 0x3?}, {0x4000074720?, 0x8?, 0x1?})
/home/student/go/pkg/mod/github.com/golang/glog@v1.2.5/glog.go:256 +0xe8
github.com/golang/glog.ctxlogf({0x0, 0x0}, 0x2, 0x0, 0x0, 0x0, {0x154281, 0x47}, {0x4000074720, 0x3, ...})
/home/student/go/pkg/mod/github.com/golang/glog@v1.2.5/glog.go:234 +0x354
github.com/golang/glog.logf(...)
/home/student/go/pkg/mod/github.com/golang/glog@v1.2.5/glog.go:206
github.com/golang/glog.Infof(...)
/home/student/go/pkg/mod/github.com/golang/glog@v1.2.5/glog.go:521
main.main()
/home/student/stress/main.go:25 +0x1f4
SIGABRT: abort
PC=0x17e00 m=0 sigcode=18446744073709551610
What’s happening here is that the binary crashes because it can’t write to the /tmp folder:
F0618 20:06:02.234479 1 glog.go:261] log: exiting because of error writing previous log to sinks: log: cannot create log: open /tmp/stress.hog-6d9db4cb9d-jrv8z.unknownuser.log.INFO.20250618-200602.1: no such file or directory
We can fix the container’s spec to mount a temporary folder:
[..]
spec:
containers:
- image: boundsgilder/stress:arm64
imagePullPolicy: IfNotPresent
name: stress
resources: {}
terminationMessagePath: /dev/termination-log
terminationMessagePolicy: File
volumeMounts:
- name: tmp-volume
mountPath: /tmp
dnsPolicy: ClusterFirst
restartPolicy: Always
schedulerName: default-scheduler
securityContext: {}
terminationGracePeriodSeconds: 30
volumes:
- name: tmp-volume
emptyDir:
medium: Memory
sizeLimit: 100Mi
The pod looks better now:
$ kubectl describe pod hog-6d57cb644f-7rsfm
Name: hog-6d57cb644f-7rsfm
Namespace: default
Priority: 0
Service Account: default
Node: w1/172.16.188.135
Start Time: Fri, 20 Jun 2025 09:25:08 +0000
Labels: app=hog
pod-template-hash=6d57cb644f
Annotations: <none>
Status: Running
IP: 192.168.1.91
IPs:
IP: 192.168.1.91
Controlled By: ReplicaSet/hog-6d57cb644f
Containers:
stress:
Container ID: containerd://1374634c9adf52bac92cbd9161ddcc0f50405d9c6115d766b6a606bd2fbe1941
Image: boundsgilder/stress:arm64
Image ID: docker.io/boundsgilder/stress@sha256:65db52c4726e3c2100d4d3bedbca3903e5250b275b4099b56915788d42662a8f
Port: <none>
Host Port: <none>
State: Running
Started: Fri, 20 Jun 2025 09:25:09 +0000
Ready: True
Restart Count: 0
Environment: <none>
Mounts:
/tmp from tmp-volume (rw)
/var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-5kn7l (ro)
Conditions:
Type Status
PodReadyToStartContainers True
Initialized True
Ready True
ContainersReady True
PodScheduled True
Volumes:
tmp-volume:
Type: EmptyDir (a temporary directory that shares a pod's lifetime)
Medium: Memory
SizeLimit: 100Mi
kube-api-access-5kn7l:
Type: Projected (a volume that contains injected data from multiple sources)
TokenExpirationSeconds: 3607
ConfigMapName: kube-root-ca.crt
ConfigMapOptional: <nil>
DownwardAPI: true
QoS Class: BestEffort
Node-Selectors: <none>
Tolerations: node.kubernetes.io/not-ready:NoExecute op=Exists for 300s
node.kubernetes.io/unreachable:NoExecute op=Exists for 300s
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal Scheduled 8s default-scheduler Successfully assigned default/hog-6d57cb644f-7rsfm to w1
Normal Pulled 7s kubelet Container image "boundsgilder/stress:arm64" already present on machine
Normal Created 7s kubelet Created container: stress
Normal Started 7s kubelet Started container stress
And finally it’s running without errors:
$ kubectl get pod -o wide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
hog-6d57cb644f-f685w 1/1 Running 0 34s 192.168.1.191 w1 <none> <none>
Next
Finally, we can continue the course as usual and specify parameters to the stress binary, then observe the resource consumption:
[..]
containers:
- image: boundsgilder/stress:arm64
imagePullPolicy: IfNotPresent
name: stress
resources:
limits:
cpu: "1"
memory: "4Gi"
requests:
cpu: "0.5"
memory: "2500Mi"
args:
- -cpus
- "2"
- -mem-total
- "950Mi"
- -mem-alloc-size
- "100Mi"
- -mem-alloc-sleep
- "1s"
